Okuma
GENOS L400II-e(Lx1100)
Mesin dengan keakurasi sangat tinggi, sangat stabil dan bodi yang ringkas benar-benar menghasilkan produktivitas tinggi.
Berikan bintang
Okuma
GENOS L400II-e(Lx1100)
Mesin dengan keakurasi sangat tinggi, sangat stabil dan bodi yang ringkas benar-benar menghasilkan produktivitas tinggi.
Berikan bintang
Tentang Produk
| Spec extension | Model name | GENOS L400II-e(Lx1100) |
|
Capacity |
Max turning dia ( mm ) | Ø410 |
| Max work length ( mm ) | 1,1 | |
|
Travels |
X axis (mm) | 230 (205+25) |
| Z axis (mm) | 1,144 | |
|
Spindle |
Spindle speed ( min-1 ) | 3 |
| Spindle nose | JIS A2-8 | |
|
Turret |
Turret type | NC V8 |
| No. of tools | 8 | |
| OD tool shank (mm) | 25×25 | |
| ID tool shank dia (mm) | Ø40 | |
|
Feedrates |
Spindle speed min-1(rpm) | X:25,Z:30 |
| Speed range | 0.001~1,000.000 | |
|
Tailstock |
Tailstock quill diameter (mm) | Ø90 |
| Tapered bore type | MT.4 (revolving center) | |
| Quill travel (mm) | 100 | |
|
Motors |
Main spindle(30min/cont) (kW) | VAC 15/11 |
| Coolant pump motor (kW) | 0.8 | |
|
Machine size |
Height (mm) | 2,057 |
| Floor space (mm) | 3,537×2,350 | |
| Weight (kg) | 6 | |
| CNC | OSP-P300LA-e |
| Spec extension | Model name | GENOS L400II-e(Lx1100) |
|
Capacity |
Max turning dia ( mm ) | Ø410 |
| Max work length ( mm ) | 1,1 | |
|
Travels |
X axis (mm) | 230 (205+25) |
| Z axis (mm) | 1,144 | |
|
Spindle |
Spindle speed ( min-1 ) | 3 |
| Spindle nose | JIS A2-8 | |
|
Turret |
Turret type | NC V8 |
| No. of tools | 8 | |
| OD tool shank (mm) | 25×25 | |
| ID tool shank dia (mm) | Ø40 | |
|
Feedrates |
Spindle speed min-1(rpm) | X:25,Z:30 |
| Speed range | 0.001~1,000.000 | |
|
Tailstock |
Tailstock quill diameter (mm) | Ø90 |
| Tapered bore type | MT.4 (revolving center) | |
| Quill travel (mm) | 100 | |
|
Motors |
Main spindle(30min/cont) (kW) | VAC 15/11 |
| Coolant pump motor (kW) | 0.8 | |
|
Machine size |
Height (mm) | 2,057 |
| Floor space (mm) | 3,537×2,350 | |
| Weight (kg) | 6 | |
| CNC | OSP-P300LA-e |
